Sweeping machine CE-RED certification——ZRLK

The sweeper is a kind of intelligent household appliances, which can automatically complete the floor cleaning work in the room by virtue of a certain artificial intelligence. Generally, the method of brushing and vacuuming is used to first absorb the ground debris into its own garbage storage box, thereby completing the function of ground cleaning. However, in general, this kind of wireless products need to apply for CE-RED certification if they want to export to Europe.

Introduction to RED certification

The 1999/5/EC directive has been implemented for many years, and existing products cannot be satisfied in many places. On May 22, 2014, the European Union officially announced a new version of the wireless equipment directive RED 2014/53/EU. This directive is based on the European Union’s new CE framework resolution 768/2008/EC. RED 2014/53/EU replaces the original The European Union Radio Equipment Directive R&TTE-D 1999/5/EC.

Sweeping machine CE-RED certification test standard

Electrical Safety (LVD): EN 62368-1:2014+A11:2017.

Electromagnetic compatibility (EMC): EN 301489-1 V2.2.3 (General Provisions), EN 301489-17 V3.2.0 (Bluetooth, WALN).

Radio Frequency (RF): EN 300328 V2.2.2.

Health (SAR): EN 62479:2010 (or EN 50663:2017, less than 20mW can be excluded).

Materials to be prepared for CE-RED certification application for sweeper

1. User manual

2. Circuit schematic diagram

3. Circuit block diagram (Block Diagram, also called module function diagram)

4. Circuit layout (PCB LAYOUT)

5. PCB placement

6. Operation description (explanation of block diagram)

7. BOM LIST

8, label (label)

9. Antenna specifications (or antenna gain diagram)

10. Charger LVD report

11. Fixed frequency software (also called fixed frequency program. The transmitter module can be set to transmit continuously at a certain frequency point, generally BT and WIFI must be provided)

Sweeping machine CE-RED certification process

1. Project application-submit an application for CE certification to the supervision of the testing agency.

2. Document preparation-According to CE certification requirements, the company prepares relevant certification documents.

3. Product testing-the company sends the samples to be tested to the laboratory for testing.

4. Compilation report-The certified engineer compiles the report based on the qualified test data.

5. Submit for review-the engineer will review the complete report.

6. Certificate issuance-CE certification will be issued after the report is verified.

Please contact our company ZRLK for CE-RED certification for sweepers. We will provide you with professional and efficient testing and certification services, with favorable prices and courteous service. If you provide us with product pictures and specifications, we will give us the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire!
